Động Cơ Bước Vít Me Lead Screw Stepper Motor Truct Tịnh Tiến
NEMA 8 Stepper Motor Lead Screw Linear Actuator
NEMA8 (20mm) External Linear Stepper Motor has the characteristics of small size, high performance, long durability, low noise and high efficiency. The base size is 20mm, and the body length is available in 30mm and 38mm.
Optional: Connectors, integrated drivers…
Optional: Connectors, integrated drivers…
| MODEL | Rated Current （A） |
Phase Resistance（Ω） | Weight （g） |
Lead Wire （No.) |
Motor Length (mm) |
| 20HSG28 | 0.5 | 5.3 | 52 | 4 | 28 |
| 20HSG38 | 0.5 | 8.8 | 75 | 38 |
| Screw Diameter （mm） |
Screw Lead （mm） |
Screw Starts | Step Length （1.8°） |
| 3.505 | 0.6096 | 1 | 0.0030 |
| 1.2192 | 1 | 0.0061 | |
| 2.0000 | 2 | 0.0100 | |
| 4.0000 | 4 | 0.0200 | |
| 8.0000 | 8 | 0.0400 |
NEMA 11 Stepper Motor Lead Screw Linear Actuator
NEMA11 (28mm) External Linear Stepper Motor has the characteristics of small size, high performance, long durability, low noise and high efficiency. The base size is 28mm, and the body length is available in 32mm, 45mm and 51mm.
Optional: Connectors, gearbox, encoder, integrated built-in drivers…
Optional: Connectors, gearbox, encoder, integrated built-in drivers…
| MODEL | Rated Current （A） |
Phase Resistance（Ω） | Weight （g） |
Lead Wire （No.) |
Motor Length (mm) |
| 28HSG33 | 0.5 | 9.1 | 120 | 4 | 33 |
| 28HSG33 | 1.0 | 2.1 | |||
| 28HSG44 | 1.0 | 4.1 | 178 | 4 | 44 |
| 28HSG51 | 1.0 | 1.5 | 195 | 51 |
| Screw Diameter （mm） |
Screw Lead （mm） |
Screw Starts | Step Length （1.8°） |
| 3.505 | 0.6350 | 1 | 0.0030 |
| 1.2700 | 1 | 0.0064 | |
| 2.5400 | 2 | 0.0127 | |
| 5.0800 | 8 | 0.0254 | |
| 10.1600 | 10.1600 | 0.0508 | |
| 5 | 2 | 1 | 0.0100 |
| 5.6 | 4.8768 | 4 |
NEMA 14 Stepper Motor Lead Screw Linear Actuator
NEMA14 (35mm) External Linear Stepper Motor has the characteristics of small size, high performance, long durability, low noise and high efficiency. The base size is 35mm, and the body length is available in 28mm, 34mm and 42mm.
Optional: Connectors, gearbox, encoder, integrated built-in drivers…
Optional: Connectors, gearbox, encoder, integrated built-in drivers…
| MODEL | Rated Current （A） |
Phase Resistance（Ω） | Weight （g） |
Lead Wire （No.) |
Motor Length (mm) |
| 35HSG33 | 0.5 | 13.2 | 190 | 4 | 33.5 |
| 35HSG33 | 1.0 | 3.5 | |||
| 35HSG33 | 1.5 | 1.8 | |||
| 35HSG45 | 0.5 | 24 | 240 | 45 | |
| 35HSG45 | 1.0 | 6 | |||
| 35HSG45 | 1.5 | 2.7 |
| Screw Diameter （mm） |
Screw Lead （mm） |
Screw Starts | Step Length （1.8°） |
Step Length （0.9°） |
| 6.35 | 0.6096 | 1 | 0.0030 | 0.0015 |
| 1.2700 | 1 | 0.0064 | 0.0032 | |
| 1.5875 | 1 | 0.0079 | 0.0040 | |
| 2.4384 | 2 | 0.0122 | 0.0061 | |
| 2.5400 | 2 | 0.0127 | 0.0064 | |
| 3.1750 | 2 | 0.0159 | 0.0079 | |
| 4.8768 | 4 | 0.0244 | 0.0122 | |
| 5.0800 | 4 | 0.0254 | 0.0127 | |
| 6.3500 | 4 | 0.0318 | 0.0159 | |
| 9.7536 | 6 | 0.0488 | 0.0244 | |
| 12.7000 | 8 | 0.0635 | 0.0318 | |
| 25.4000 | 8 | 0.1270 | 0.0635 | |
| 8.0 | 1.5000 | 1 | 0.0075 | 0.0038 |
| 2.0000 | 1 | 0.0100 | 0.0050 | |
| 4.0000 | 2 | 0.0200 | 0.0100 | |
| 8.0000 | 4 | 0.0400 | 0.0200 | |
| 12.0000 | 6 | 0.0600 | 0.0300 | |
| 15.0000 | 6 | 0.0750 | 0.0375 | |
| 20.0000 | 8 | 0.1000 | 0.0500 |
NEMA 17 Stepper Motor Lead Screw Linear Actuator
NEMA17 (42mm) External Linear Stepper Motor has the characteristics of small size, high performance, long durability, low noise and high efficiency. The base size is 42mm, and the body length is available in 34mm, 40mm, 48mm and 60mm.
Optional: Connectors, gearbox, encoder, integrated built-in drivers…
Optional: Connectors, gearbox, encoder, integrated built-in drivers…
| MODEL | Rated Current （A） |
Phase Resistance（Ω） | Weight （g） |
Lead Wire （No.) |
Motor Length (mm) |
| 42HSG34 | 0.5 | 12 | 255 | 4 | 34 |
| 42HSG34 | 1.0 | 3.8 | |||
| 42HSG40 | 0.5 | 1.9 | 388 | 4 | 40 |
| 42HSG40 | 1.5 | 22 | |||
| 42HSG48 | 1.7 | 1.7 | 310 | 48 | |
| 42HSG60 | 2.0 | 0.9 | 360 | 60 |
| Screw Diameter （mm） |
Screw Lead （mm） |
Screw Starts | Step Length （1.8°） |
Step Length （0.9°） |
| 6.35 | 0.6096 | 1 | 0.0030 | 0.0015 |
| 1.2700 | 1 | 0.0064 | 0.0032 | |
| 1.5875 | 1 | 0.0079 | 0.0040 | |
| 2.4384 | 2 | 0.0122 | 0.0061 | |
| 2.5400 | 2 | 0.0127 | 0.0064 | |
| 3.1750 | 2 | 0.0159 | 0.0079 | |
| 4.8768 | 4 | 0.0244 | 0.0122 | |
| 5.0800 | 4 | 0.0254 | 0.0127 | |
| 6.3500 | 4 | 0.0318 | 0.0159 | |
| 9.7536 | 6 | 0.0488 | 0.0244 | |
| 12.7000 | 8 | 0.0635 | 0.0318 | |
| 25.4000 | 8 | 0.1270 | 0.0635 | |
| 8.0 | 1.5000 | 1 | 0.0075 | 0.0038 |
| 2.0000 | 1 | 0.0100 | 0.0050 | |
| 4.0000 | 2 | 0.0200 | 0.0100 | |
| 8.0000 | 4 | 0.0400 | 0.0200 | |
| 12.0000 | 6 | 0.0600 | 0.0300 | |
| 15.0000 | 6 | 0.0750 | 0.0375 | |
| 20.0000 | 8 | 0.1000 | 0.0500 |
NEMA 23 Stepper Motor Lead Screw Linear Actuator
NEMA23 (57mm) External Linear Stepper Motor has the characteristics of small size, high performance, long durability, low noise and high efficiency. The base size is 57mm, and the body length is available in 41mm, 51mm, 56mm, 76mm, 82mm, 100mm, and 112mm.
Optional: Connectors, gearbox, encoder, integrated built-in drivers…
Optional: Connectors, gearbox, encoder, integrated built-in drivers…
| MODEL | Rated Current （A） |
Phase Resistance（Ω） | Weight （g） |
Lead Wire （No.) |
Motor Length (mm) |
| 57HSG45 | 1 | 6.4 | 0.8 | 4 | 45 |
| 57HSG45 | 2.0 | 1.2 | |||
| 57HSG45 | 3.0 | 0.9 | |||
| 57HSG65 | 3.0 | 1.2 | 1.2 | 65 | |
| 57HSG65 | 4.0 | 0.7 | |||
| 1.5 | 2.7 |
| Screw Diameter （mm） |
Screw Lead （mm） |
Screw Starts | Step Length （1.8°） |
Step Length （0.9°） |
| 9.525 | 1.27 | 1 | 0.0064 | 0.0032 |
| 2.54 | 1 | 0.0127 | 0.0064 | |
| 3.175 | 1 | 0.0159 | 0.0079 | |
| 5.08 | 4 | 0.0254 | 0.0127 | |
| 6.35 | 4 | 0.0318 | 0.0159 | |
| 9.525 | 4 | 0.0476 | 0.0238 | |
| 10.16 | 8 | 0.0508 | 0.0254 | |
| 12.7 | 4 | 0.0635 | 0.0318 | |
| 25.4 | 8 | 0.1270 | 0.0635 | |
| 10 | 2 | 1 | 0.0100 | 0.0050 |
| 4 | 2 | 0.0200 | 0.0100 |
NEMA 24 Stepper Motor Lead Screw Linear Actuator
Stepper motor, high torque, low noise, smooth type, step angle: 1.8° NEMA24, 60x60mm
Optional: Lead-wires, gearbox, encoder, brake, integrated drivers…
Optional: Lead-wires, gearbox, encoder, brake, integrated drivers…
| MODEL | Rated Current （A） |
Phase Resistance （Ω） | Weight （Kg） |
Lead Wire （No.) |
Motor Length（mm） |
| 60HSG47 | 2.0 | 1.5 | 1 | 4 | 47 |
| 60HSG47 | 3.0 | 0.6 | |||
| 60HSG67 | 3.0 | 1.2 | 1.5 | 67 | |
| 60HSG67 | 4.0 | 0.6 |
| Screw Diameter （mm） |
Screw Lead （mm） |
Screw Starts | Step Length （1.8°） |
Step Length （0.9°） |
| 9.525 | 1.27 | 1 | 0.0064 | 0.0032 |
| 2.54 | 1 | 0.0127 | 0.0064 | |
| 3.175 | 1 | 0.0159 | 0.0079 | |
| 5.08 | 4 | 0.0254 | 0.0127 | |
| 6.35 | 4 | 0.0318 | 0.0159 | |
| 9.525 | 4 | 0.0476 | 0.0238 | |
| 10.16 | 8 | 0.0508 | 0.0254 | |
| 12.7 | 4 | 0.0635 | 0.0318 | |
| 25.4 | 8 | 0.1270 | 0.0635 | |
| 10 | 2 | 1 | 0.0100 | 0.0050 |
| 4 | 2 | 0.0200 | 0.0100 |
NEMA 34 Stepper Motor Lead Screw Linear Actuator
NEMA 34 Stepper Motor Lead Screw Linear Actuator is designed for high-performance applications requiring precise linear motion, robust torque, and rapid acceleration. Featuring a NEMA 34 (86x86mm) frame size, this actuator integrates a low rotor inertia stepper motor, optimized for delivering large torque and fast acceleration. Available in 2-phase (1.8° step angle) or 3-phase (1.2° step angle) configurations, it ensures smooth and accurate positioning for demanding industrial tasks.
| MODEL | Rated Current （A） |
Phase Resistance（Ω） | Weight （g） |
Lead Wire （No.) |
Motor Length (mm) |
| 86HSG75 | 5 | 0.75 | 2.5 | 4 | 75 |
| 86HSG98 | 5 | 0.6 | 3.5 | 98 | |
| 86HSG1180 | 6 | 0.6 | 5 | 4 | 118 |
| 86HSG156 | 6 | 0.7 | 6 | 156 |
| Screw Diameter （mm） |
Screw Lead （mm） |
Screw Starts | Step Length （1.8°） |
| 2.5400 | 1 | 0.0127 | |
| 3.1750 | 1 | 0.0159 | |
| 5.0800 | 2 | 0.0254 | |
| 6.3500 | 2 | 0.0318 | |
| 12.7000 | 4 | 0.0635 | |
| 25.4000 | 8 | 0.1270 |
